The Titan HV Power Supply is designed for high speed, high power capacitor charging applications at voltages up to 120kV, 45kJ/sec and PRF’s as high as 250Hz.
It uses a rugged IGBT based inverter running in resonant mode to achieve high efficiency and excellent ruggedness. It is designed to run, either from a high DC voltage input (typically 550V), or from UK/EU3-phase input.
| Input Voltage | 550VDC or 415VAC 3Phase |
|---|---|
| Input Frequency | 50Hz to 60Hz in AC |
| Output Voltage DC | 60kV and 120kV |
| Output Power | Average 45000J/s |
| Polarity | Positive or Negative |
| Output Adjustable Range | 0 to 100% Voltage |
| Operating Temperature | '-10°C to +40°C |
| Operating Humidity | < 90% non-condensing |
| Cooling Method | Forced Air |
| Control | Local, Local and Remote, Remote |
| Monitoring | Local and Remote |
| Dimension | 400*483*560mm or 489*605*780mm |
| Weight | 70kg or 100kg |
